Current escapes its intended path and flows through the ground (earth) instead of returning through the neutral conductor. This creates an unintended circuit between a live conductor and earth, which can be dangerous and destructive.
Effects on the inverter
- Overcurrent damage -Fault current spikes far above rated capacity.
- IGBT / transistor failure – Switching devices burn out instantly under fault load.
- Capacitor failure – DC bus caps discharge violently through fault.
- Nuisance tripping – Protection circuits shutdown inverter unexpectedly.
- Fire and arcing risk – Sustained fault current generates extreme heat.
- DC bus overvoltage – Voltage rises on bus when return path is disrupted.
- Insulation breakdown – Repeated faults degrade winding insulation over time.
- Control board damage – Fault voltage can reach low-voltage logic circuits.
- Leakage current – Personnel shock hazard on inverter enclosure.
How to prevent ground faults
What a ground fault actually is?
When everything is working normally, current leaves the source, does its job, and comes back through the neutral. A ground fault is when that return path breaks down and current finds a shortcut — through the inverter chassis, through the ground wire, or through a person. The inverter never expected that path, so it has no way to handle it gracefully.
Why inverters get hit so hard?
An inverter sits between a DC source (like a battery bank or solar array) and an AC load. That means it carries high-energy current on both sides. When a fault hits, the DC bus capacitors — which store a significant amount of energy — can dump all of that energy through the fault point in milliseconds. The switching transistors (usually IGBTs) are the first casualties because they simply cannot survive current levels that high. Most quality inverters have built-in protection, but a hard fault can destroy hardware faster than any protection circuit can respond.
The solar PV specific problem
On a solar array, a ground fault on the DC overloading wiring is one of the most dangerous failures in the industry. Unlike AC circuits, there is no natural zero crossing — meaning the fault arc burns continuously and will not self-extinguish. Several large solar farm fires have been traced directly to undetected DC ground faults. Most modern grid-tied inverters include a Ground Fault Protection Device (GFPD) specifically for this reason.
Prevention in plain terms
Good grounding is not just about compliance — it gives the fault current a safe, controlled path so protection devices can detect and interrupt it quickly. RCDs work by comparing current going out versus coming back; any difference (as small as 5–30 mA) means current is leaking somewhere it should not, and the device trips. Shielded cables are important on the motor/output side of variable-frequency drives because the PWM switching creates high-frequency signals that couple capacitively to earth — that shows up as leakage current even without a true fault, and can false-trip sensitive protection.
The single most preventable cause of ground faults in field installations is compromised cable insulation — either from routing cables near sharp edges, rodent damage, or using undersized cable in high-temperature environments. A megger test once a year catches this before it becomes a failure.
Conclusion
Ground faults may seem like a minor electrical issue, but they can have a significant impact on inverter performance, system safety, and energy generation. Regular maintenance, proper grounding, high-quality components, and continuous monitoring are key to preventing ground faults and ensuring the long-term reliability of a solar power system.
By taking preventive measures today, solar system owners can protect their investment and enjoy safe, efficient, and uninterrupted solar production for years to come.
